£2,850.00 inc. VAT
£2,375.00 exc. VAT
| 1/2HP Trumpet | 3/4HP Trumpet | 1HP Trumpet | 3HP Trumpet |
Pattern Height | 1.15 Metres | 1.70 Metres | 1.70 Metres | 2.0 Metres |
Pattern Width | 4.30 Metres | 6.10 Metres | 6.70 Metres | 7.30 Metres |
Maximum Pond Size for Aeration (Acre) | 0.3 | 0.5 | 0.75 | 2 |
Maximum Pond Size for Aeration (M²) | 1,300 | 2,000 | 3,000 | 8,000 |
Min Pond Depth | 450mm | 450mm | 490mm | 610mm |
Voltage | 220-240V/50Hz | 220-240V/50Hz | 220-240V/50Hz | 220-240V/50Hz |
Phase | 1 Phase | 1 Phase | 1 Phase | 1 Phase |
Starting Amps | 5.3 | 12.8 | 19.6 | 59.7 |
Running Amps | 2.2 | 3.6 | 5.9 | 12.5 |
Motor HP | 0.5 | 0.75 | 1 | 3 |
Motor Watts | 484 | 748 | 814 | 2618 |
Supplied Cable Length | 10 Metres | 10 Metres | 10 Metres | 1 Metre ‘Stub’ |
Recommended Maximum Cable Run | Unlimited, but cable should be sized appropriately for the total length | |||
Recommended Cable for 10 Metre Run | 1.5mm² (Cable Pre-Fitted) | 1.5mm² | ||
Recommended Cable for 30 Metre Run | 1.5mm² | 1.5mm² | 1.5mm² | 2.5mm² |
Recommended Cable for 60 Metre Run | 2.5mm² | 2.5mm² | 2.5mm² | 6mm² |
Recommended Cable for 90 Metre Run | 2.5mm² | 2.5mm² | 4mm² | 6mm² |
Recommended Cable (100 Metres +) | Consult an electrician or contact us for advice | |||
Suction Strainer | 3 Pieces | 3 Pieces | 3 Pieces | 1 Piece |
Mooring Ropes Supplied | 2 x 15 Metres | 2 x 15 Metres | 2 x 15 Metres | 3 x 15 Metres |
Anchors | Not Supplied | |||
Warranty | 2 Years | 2 Years | 2 Years | 2 Years |

Mooring or anchoring of the aerating fountain can be done using the supplied 15 metre heavy duty tethering ropes. Models 1/2HP, 3/4HP and 1HP are supplied with 2 ropes attached the the float and should be secured from 2 positions. The more powerful 3HP model is supplied with 3 tethering ropes and should be fixed from 3 positions. The fountain can be tethered either by mooring from the bank side, or anchoring using suitable ballast such as concrete slabs (not supplied). The power cable should fall vertically to the pond floor and kept slack.
