Tradux Wall and Liner Transition Piece

The OASE Tradux Underwater Transition is suitable for connecting flexible pond hose or electrical cables (3mm to 9mm diameter) through flexible rubber Pond Liners.  The large clamping surface area ensures a watertight seal around the 2" BSP Male threaded connector, so hoses can be passed below water level as well as above.

• Also suitable for pool and tank walls up to 14mm thick.
• Includes multistage hosetails up to 2 inch diameter.
• Can accept 3/4", 1", 1 1/4", 1 1/2" and 2" internal bore Flexible Pond Hose.
• 2" BSP Male Threaded Connections fitted directly to both sides of main transition piece.

A hole of 60-63mm in diameter should be cut in pond liner or tank wall in order to accommodate the Tradux threaded pipe. The 2" BSP pipe thread measures approximately 59mm in outside diameter.

Please note that 2 tradux Transition kits are required if fitting 1 x hose and 1 x cable through a pond liner or wall (i.e. Pump Hose and Pump Cable).
