£725.99 inc. VAT
£604.99 exc. VAT
Our 1500mm Waterfall Blade Kits are designed to be easy to install and include everything you need to create a contemporary waterfall feature. The 1500mm Waterfall Blade Kit is supplied with either a standard or extended lip 1500mm stainless steel blade that can be built into newly constructed walls or installed on flat vertical surfaces such as an existing exterior wall or railway sleepers at a maximum height of 1 metre above water's surface.
Our Waterfall Blade Kits also include a suitable pump and fittings kit to make installation as easy as possible using the standard 1" BSP threaded connection points in the rear and bottom of the blade to suit a variety of requirements.
The standard water blade features a lip measuring 60mm. The extended blade features a 130mm lip, ideal for extending reach, or disguising the blade deeper within the wall.Find out more
The 1500mm Waterfall Blade Kit Includes:
Water Blades with Dual Entry Hose Connections.
Water Blades with dual entry hose connections feature a centrally located inlet at the rear, and also another central inlet in the same position on the bottom of the water blade. This dual entry design allows the connecting flexible pipe to be attached from back of the blade or up from the bottom, depending on the most convenient position for pipe entry based on the intended installation method. This innovative design approach allows dual entry water blades to be installed in a variety of ways, such as being built into new walls, or mounted to the face of existing surfaces with the pipe entering via either point of inlet. There is a plug supplied with each dual entry water blade which can be screwed into the inlet not being used.
Rear Entry Hose Connection.
Rear entry hose connection is the preferred method of pipe connection for the majority of water blade installations. This is because pipework is easier to hide when entering through the wall from the rear. Pipe connection from the rear is commonly the chosen method for supplying to water blades built into new walls as part of the fixed structure, as the flexible pipe can be hidden from view, entering the water blade through the back of the wall, leaving the water blade cascade lip as the only visible component. Rear entry pipe connection can also be achieved when mounting a water blade to an existing wall or surface by channelling the pipe through the wall and securing the water blade to the front face using a mounting bracket.
Bottom Entry Hose Connection.
Bottom entry hose connection is a more common practice when fixing a water blade onto an existing wall, in situations where the water blade cannot be incorporated into the original build and must therefore be secured to the front face of the wall using a mounting bracket. Bottom entry pipe connection is also done in instances where a single skin wall is constructed, as the wall face can be channelled out to accept the blade and hose. The wall is then finished by applying a screed over the recessed blade box and pipework.
Standard Water Blade - 60mm Waterfall Lip.
A standard water blade features a spillway lip which protrudes 60mm from the main water blade box. When building a water blade into a wall, a standard water blade will allow for up to 60mm of protrusion from the wall, depending on how deep within the wall the water blade is housed. The same rule applies to a bottom entry water blade recessed into a single skinned wall. When mounted onto the outer face of an existing surface, the standard water blade will extend to around 130mm from the wall face, accounting for both the lip and the unit body.
Extended Water Blade - 130mm Waterfall Lip.
An extended water blade features a 130mm long spillway lip. This type of blade will offer extended protrusion from the wall face and can be used in instances where thicker building materials are used in construction. The extended water blade can be installed deeper within the wall allowing for a further layer of construction material to be built up in front of the main body of the blade to hide it, whilst still reaching far enough from the wall to allow the waterfall to cascade independent of the wall face.
|Number of Inlets||3|
|Inlet BSP Thread (Rear or Bottom)||3 x 1" BSP (Female Internal Thread)|
|Required Flow Rate at Discharge Height (LPH)||12000||15000|
|Required Flow Rate at Discharge Height (LPM)||200||250|
|Construction Material||Stainless Steel|
|Maximum Flow Rate (Litres Per Hour)||19100||25000|
|Maximum Delivery Head (Metres)||6.3||9.5|
|Power Supply||230V / 50Hz|
|Cable Length||10 Metres|
|Power Consumption (Watts)||318||620|
|IP Rating||IP68 (Fully Submersible)|
|Dry-Mount (Flooded Suction)||Can be dry installed below water level and operated by flooded suction|
|Dimensions L x W x H (cm)||40 x 16.5 x 19|
Note: Water Garden Ltd specify these pumps based on the required flow rate of each water blade and the height at which it is installed. We also account for the resultant friction losses that occur through connecting flexible hose (supplied with our fittings kits) in order to ensure that the pump we recommend is capable of the task.
|Pipe Internal Diameter||25mm (black smooth bore flexible hose)|
|Pipe External Diameter||30mm (smooth exterior)|
|Pipe Length Supplied||15 Metres|
|Flow Regulator||3 Way Flow Splitter with 3 Individual Flow Valves|
|90° Elbows||3 x 25mm Barbed Elbow/Hosetails|
|Blade Inlet Hosetails||3 x 1" BSP (Male) 25mm Hosetails|
|Stainless Steel Hoseclips||14 x SK19 Clips for 1" ID Flexible Hose|
|PTFE Tape||1 x Roll 10m x 0.1m|
Note: Water Garden Ltd construct our own high quality pipe & fittings kits. These contain high performance fittings which are designed to last. We do not supply low quality flexible hose ('Aquatic' hose) as this will degrade quickly and is liable to split. If there is anything specific that you require to complete your installation (i.e. larger diameter hoses, reducing sockets, extra hosetail connectors etc), give us a call to discuss your requirement and we will aim to tailor your fittings kit to suit you (additional costs may be incurred on non-standard components).
