PondJet ECO RGB Fountain Set | OASE Fountains - Water Garden UK
  • PondJet ECO - RGB Fountain Set

    • Get a free £100 Digital Gift Voucher with this product

      To be used on your next purchase with us

  • QTY

    £2,060.00 inc. VAT

    £1,716.67 exc. VAT

Description

PondJet - LED - RGB

The submersible pump is suspended from the underside of the float assembly, allowing clearer water to be pumped up to the integrated 12 jet decorative fountain nozzle (supplied).  Due to the floating design, the PondJet ECO can be used in heavily sedimented ponds and lakes or for use where water level fluctuations occur.

The Pond Jet ECO will require a minimum water depth of 1 metre (3ft) in clear water or 1.5 metres in silted water.  The special Pump is supplied with 20 metres of 230 Volt electrical cable and the float comes complete with anchoring points for securing to the pond or lake floor (we suggest the use of heavy duty fishing wire tied to a suitable weight, to anchor the fountain float and maintain the position within the pond area).

RGB Lighting Set wFM-Master

The RGB spotlights and submersed driver can be connected to the supplied FM Master WLAN's DMX-RDM Port with the supplied 20 metre EGC Connection cable, and the 20 metre mains cable is then wired into one of the 3 on/off ports.  The Lighting can then be controlled via the free OASE App, allowing you adjust the colours, fix the colour or allow these colours to cycle through.  Both the RGB Lights and the PondJet can also be set on individual 24 hour timers, again via the App.

The supplied FM Master WLAN Controller can be mounted on dry land, with the PondJet floating fountain and RGB Light Set connected.  The WLAN controller will allow on/off control of the fountain pump but will also control the fountain display height via the free Oase App and your smart phone/tablet (iOS 7.x or higher and Android 4.0.3 or higher).  Two spare on/off ports remain on the WLAN controller for supplemental garden lighting or other electrical devices.

Product video

Additional Information

Technical Info

Technical Info

ProfiLux LED RGB Spot Light Set

Pond Jet Floating Fountain ProfiLux LED RGB Light Set

Dimensions Light FixtureDiameter 80mm x Height 117mm
Number of Light Fixtures3
Rated Voltage Light Light Fixtures24V DC
Protection Class Light FixturesIP 68 (Fully Submersible to 4 metres)
Power Consumption per Light Fixture6 watts
Power Consumption (Set)19 watts
Cable Length Light Fixtures5 metres
Net Weight Set8 kg
Guarantee Light Fixtures2 + 1 years (2 years with 1 year free extension)
Connection for EGCYes
Illuminant Type Light FixturesLED
Number of LED per Light Fixture3
LED Light Colour RGB (Red, Green, Blue)
Light Flux (all LED on)213 lumens
Light Flux Red LED64 lumens
Light Flux Green LED114 lumens
Light Flux Blue LED35 lumens
Half Peak Beam Angle Light Fixture25 degrees

24 Volt ProfiLux LED RGB Transformer

Dimensions Transformer
Rated Voltage Transformer230V / 50Hz - 24V DC
Protection Class TransformerIP 68 (Fully Submersible to 4 metres)
Cable Length Transformer20 metres
Net Weight Transformer
Guarantee Transformer2 + 1 years (2 years with 1 year free extension)
Connection for EGC TransformerYes

EGC Connection Cable

EGC Cable Length WLAN to Transformer20 metres (10 metre + 10 metre via EGC Connector)
EGC Cable Cross Section0.22mm²
EGC Cable Protection Class IP 68 (Fully Submersible to 4 metres)
EGC Cable Net Weight2.6 kg

InScenio FM Master WLAN Easy Garden Control (EGC)

Dimensions FM Master WLAN EGCLength 215mm x Width 155mm x Height 295mm
Rated Voltage FM Master WLAN EGC220-240V / 50Hz
Maximum Total Power Load FM Master WLAN EGC3600 watts
Maximum Total Load Current FM Master WLAN EGC16 amps
Net Weight FM Master WLAN EGC2 kg
Guarantee FM Master WLAN EGC2 + 1 years (2 years with 1 year free extension)
Radio Range (433 MHz) Maximum80 metres
WLAN Range (2.4GHz) Maximum80 metres
Connection ECGYes - 1 x DMX/RDM Outlet
Network SuitabilityRouter / Cloud
WLAN HotspotYes
Number of On/Off Power Outlets3 x 220-240 V
Timer OptionYes - Every Power Outlet
Maximum Load per On/Off Outlet2000 watts
Number of Variable Speed Outlets1 x 220-240 V
Maximum Load Variable Speed Outlet320 watts



Performance Data

Performance Data

OASE Pond Jet Eco Floating Fountain: Performance Data

Pond Jet
Voltage
230v 50hz
Power consumption (watt)
190
Turnover rate Max (l/min)
180
Head of water max (m)
8.5
Pressure side (inch)
1" BSPF
Strainer surface (cm2)
650
Weight (kg)
9.0
Connection cable (m)
20

Pond Jet Dimensions


Pond Jet Performance Curve

PondJet ECO - RGB Fountain Set

  • £2,060.00 inc. VAT

    £1,716.67 exc. VAT
